TT-JAX ( .173" ) TWIN ROW AND THREE ROW JACK PANELS
JACK PANELS
?
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
TT-JAX ? (.173") TWIN ROW AND THREE ROW JACK PANELS
Series TT5902000
219
Jack Data
Panel Data
Series TT6102000
Part Number
Part Number
Qty.
Width
Mount
Modules
TT5902000
without jacks
0
Series TT5302000, TT5402000 (Typical)
TT5902S89
TT5902W89
TTD5902000
TT89FM
WTT89FM
without jacks
48
0
19"
TTD5902S89
TTD5902W89
TT89FM
WTT89FM
48
Stan-
24
Note
SERIES TT5902000*
Modular twin row, 1.75" high x 19" wide, standard mount.
Supplied with 24 black modules, designation strips, and
covers. Mounts 48 TT Twin-Jax ? twin jacks.
SERIES TT6002000*
Similar to TT5902000, except 23" wide. Supplied with 28
TT6002000
TTD6002000
TT6002S89
TT6002W89
TTD6002S89
TTD6002W89
TT6102000
without jacks
1
Note 1
None
0
56
56
0
23"
dard
(Black)
black modules, designation strips, and covers. Mounts 56 TT
Twin-Jax ? twin jacks.
SERIES TT6102000
Modular twin row, 1.75" high x 19" wide, flush or standoff
mount. Supplied with 24 black modules, designation strips,
and covers. Mounts 48 TT Twin-Jax ? twin jacks.
TT6102S89
TT6102W89
TT6202000
TT6202S89
TT6202W89
TT5302000
Note 1
without jacks
Note 1
without jacks
48
0
56
0
19"
23"
Flush
28
(Black)
? TT5302S95
TT95FM
SERIES TT6202000
Similar to TT6102000, except 23" wide. Supplied with 28
black modules, designation strips, and covers. Mounts 56 TT
Twin-Jax ? twin jacks.
TT5302W95
? TT5302S96
TT5302W96
TTD5302000
WTT95FM
TT96FM
WTT96FM
without jacks
48
0
19"
Stan-
dard
24
(Black)
SERIES TT5302000*
TTD5302S95
Modular three row, 1.75" high x 19" wide, standard mount.
Supplied with 24 black modules, designation strips, and
covers. Designed for LINE, EQUIP and MONITOR patch
connections. Mounts 48 Tri-Jax ? triple jacks.
SERIES TT5402000*
Similar to TT5302000, except 23" wide. Supplied with
Through
TTD5302W96
TT5402000
TTD5402000
TT5402S95
Through
Note 2
without jacks
Note 2
48
0
28 black modules, designation strips, and covers. Mounts 56
Tri-Jax ? triple jacks.
SERIES TT5702000
TT5402W96
TTD5402S95
Through
Note 2
56
23"
Stan-
dard
28
(Black)
Modular three row, 1.75" high x 19" wide, flush or standoff
TTD5402W96
mount. Supplied with 24 black modules, designation strips,
and covers. Mounts 48 Tri-Jax ? triple jacks.
TT5702000
TT5702S95
without jacks
0
SERIES TT5802000
Similar to TT5702000, except 23" wide. Supplied with
28 black modules, designation strips, and covers. Mounts
Through
TT5702W96
TT5802000
Note 2
without jacks
48
0
19"
Flush
24
(Black)
56 Tri-Jax ? triple jacks.
TT5802S95
ORDERING
1. Order part number from table
Through
TT5802W96
Note 2
56
23"
Flush
28
(Black)
2. Contact Switchcraft for any special order items.
*Prefix TTD indicates panel is pre-drilled with countersunk
holes for mounting “X-Wide” vertical designation strips.
See “DESIGNATION STRIPS” section.
? Special order only; contact Switchcraft for price and delivery.
1. Complete panel part number with jacks installed can be constructed as
shown for Series TT59 or TTD59.
2. Complete panel part number with jacks installed can be constructed as
shown for series TT53.
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
